| Input Voltage | 9~18V DC (12V) |
|---|---|
| Current Consumption | < 100mA |
| Accelerometer | Range : ±2G Resolution : 0.98mG Accuracy : ±40mG |
| Compass | Range : 0° ~ 360° Resolution : 1° Accuracy : ±10° |
| Inclinometer | Range : -180° ~ 180° Resolution : 1° Accuracy : ±5° |
| Measurement Cycle | 10ms |
| Interface | RS232, LoRa, CAN2.0A(500kbps) |
| Magnetometer | Resolution : 0.3uT Heading Accuracy : ±3° |
| Magnetometer | Resolution : 0.3uT Heading Accuracy : ±3° |
| Gyroscope | Range : ±2000°/s Resolution : 0.061°/s Accuracy : ±5°/s |
| Input Voltage | 9~18V DC (12V) | Measurement Cycle | 10ms |
|---|---|---|---|
| Current Consumption | < 100mA | Interface | RS232, LoRa, CAN2.0A(500kbps) |
| Accelerometer | Range : ±2G Resolution : 0.98mG Accuracy : ±40mG |
Magnetometer | Resolution : 0.3uT Heading Accuracy : ±3° |
| Compass | Range : 0° ~ 360° Resolution : 1° Accuracy : ±10° |
Gyroscope | Range : ±2000°/s Resolution : 0.061°/s Accuracy : ±5°/s |
| Inclinometer | Range : -180° ~ 180° Resolution : 1° Accuracy : ±5° |
