CAN to Wireless Communication Module
Smart Modules
- CAN to Wireless
Communication Module
-
CAN - Wireless Communication Module
-
Able to monitor and control vehicle devices by mobile equipment
as reading and analyzing CAN message thru wireless connection
- Wifi, Bluetooth, ZigBee
- Maximum communication distance : Class1 (more than 100M)
- Automotive insulated Dual-CAN communication circuit
implemented
Technical data
| Input Voltage |
9~18V DC (12V) |
| Current Consumption |
< 100mA |
| Communication Feature |
CAN2.0A,B 2CH, 1Mbps(Insulation)
RS485, 115.2Kbps (Insulation), RS232,115,2Kbps(Insulation)
PC Interface 921.6Kbps(Insulation)
Wifi (921.6KBPS), Bluetooth(115.2Kbps), Zigbee(115.2Kbps) Selectable
Serial Boot Loader, RTC, CPU : Cortex-M4(168MHz) |
| Input Voltage |
9~18V DC (12V) |
| Current Consumption |
< 100mA |
| Communication Feature |
CAN2.0A,B 2CH, 1Mbps(Insulation)
RS485, 115.2Kbps (Insulation), RS232,115,2Kbps(Insulation)
PC Interface 921.6Kbps(Insulation)
Wifi (921.6KBPS), Bluetooth(115.2Kbps), Zigbee(115.2Kbps) Selectable
Serial Boot Loader, RTC, CPU : Cortex-M4(168MHz) |
Application Fields
