Smart Modules
Inertial Measurement Unit (IMU)
Smart Modules
- IMU (Inertial Measurement Unit)
-
- Integrating sensors information to measure object's movement
- Built-in with 3 axes accelerometer, 3 axes gyroscope,
3 axes magnetometer
- Pressure sensor applied for altitude measurement
- Customized interface according to requirements
(CAN, RS232, Wifi, Bluetooth, ZigBee, LoRa, etc.)
- Algorithm : Kalman Filter, Madgwick, Quaternion to Euler
Technical data
| Input Voltage |
9~18V DC (12V) |
| Current Consumption |
< 100mA |
| Accelerometer |
Range : ±2G
Resolution : 0.98mG
Accuracy : ±40mG |
| Compass |
Range : 0° ~ 360°
Resolution : 1°
Accuracy : ±10° |
| Inclinometer |
Range : -180° ~ 180°
Resolution : 1°
Accuracy : ±5° |
| Measurement Cycle |
10ms |
| Interface |
RS232, LoRa, CAN2.0A(500kbps) |
| Magnetometer |
Resolution : 0.3uT
Heading Accuracy : ±3° |
| Magnetometer |
Resolution : 0.3uT
Heading Accuracy : ±3° |
| Gyroscope |
Range : ±2000°/s
Resolution : 0.061°/s
Accuracy : ±5°/s |
| Input Voltage |
9~18V DC (12V) |
Measurement Cycle |
10ms |
| Current Consumption |
< 100mA |
Interface |
RS232, LoRa, CAN2.0A(500kbps) |
| Accelerometer |
Range : ±2G
Resolution : 0.98mG
Accuracy : ±40mG |
Magnetometer |
Resolution : 0.3uT
Heading Accuracy : ±3° |
| Compass |
Range : 0° ~ 360°
Resolution : 1°
Accuracy : ±10° |
Gyroscope |
Range : ±2000°/s
Resolution : 0.061°/s
Accuracy : ±5°/s |
| Inclinometer |
Range : -180° ~ 180°
Resolution : 1°
Accuracy : ±5° |
|
|
Application Fields
